Perforated Round Metal Filter Porous Stainless Steel Discs High Temperature Resistance

Hebei Standard Filter Equipment Co.,Ltd
Contact Now

Perforated Round Metal Filter Porous Stainless Steel Discs High Temperature Resistance

  • 1
  • 2

Brand Name : STD

Model Number : STD-S

Certification : FDA ,CE,PICC,SGS,ISO

Place of Origin : China

MOQ : 1 pcs

Price : To be negotiated

Payment Terms : L/C, T/T, Western Union,

Supply Ability : 10000 pieces per day

Delivery Time : 5-10 work days

Packaging Details : Standard export packing in carton or wooden box, or as your specific requirement.

Name : Sintered porous metal filter disc

Filter Rating : 90%

Usage : Liquid Filter,Air filtration

Material : Stainless steel 304

Technical : Sintered

Color : Silver,golden

Type : Filter Disc

Hole Shape : Round

Thickness : Customer request

Width : Customer request

Application : Gas liquid filtration

Technique : Sintering

Packing : Carton or wooden

Length : Customer request

shape : round, tetragonum , customized

Contact Now

High Temperature Resistance Perforated Round Stainless Steel Metal Porous Filter Disc

Description

The filter mesh is made of stainless steel mesh or wire mesh by machine stamping. It has round, rectangular, square, oval, ring and other shapes. The main material of the black wire mesh is iron wire, which has three kinds of weaving methods: plain weave,mat weave, twill herringbone weave.

Filteration Class

Filtering Rating

(um)

Pore Size Max.

(um)

Permeability

10-12m²

Breathability

m3/h.m2.KPa

Thickness

(mm)

Compression

Strength

MPa/ cm²

S9 0.2 2.5 1 3 3.0
S8 0.5 4 3 3 3.0
S7 1.0 6 5 3 3.0
S6 2.5 10 0.09 10 3 3.0
S5 5 15 0.23 40 3 3.0
8 20 0.91 80 3 3.0
S4 10 30 1.81 160 3 3.0
S3 30 60 3.82 350 3 3.0
35 80 7.29 500 3 3.0
S2 40 100 9.43 700 3 3.0
S1 65 160 15.1 1000 3 3.0

Perforated Round Metal Filter Porous Stainless Steel Discs High Temperature ResistancePerforated Round Metal Filter Porous Stainless Steel Discs High Temperature Resistance

The Feature

High temperature resistance, corrosion resistance, burn resistance, good filtering effect, etc.

The application:

Filter mesh is mainly used for distillation in rubber, plastic particles, plastics industry, grain and oil screening, petroleum, chemical fiber, electric power, oil refining, chemical industry, light industry, sewage, beverage, medicine, metallurgy, machinery, shipbuilding, automobile and tractor industries , Absorption, evaporation, filtration equipment, etc.
